Automatic Ink Circulation System with Arduino Board – E-Book

$7.70

New 2018: Now includes a digital diagram showing how it should be connected.

File Format: PDF
File Raw Size: 21.2 MB
Includes Free Updates (If there’s any)
Arduino Source Code Included!

Description


Step by step plans to teach how to build an Automatic Ink Circulation System with Arduino Board.
Leaving white ink without shaking the bottles for a single day can be a catastrophic thing, ink will turn into water and the real ink will stick to the bottom of the bottle just like water and oil.

With this method you can forget about shaking the inks and just print like you do, also you can manage how often you want the system to circulate the ink and how long it should stay inactive.

Technical Details

Digital Content
Delivery via Download instantly after purchase.
10 Pages with illustrated images.
File Format: PDF
File Raw Size: 21.2 MB
Includes Free Updates (If there’s any)
Arduino Source code Included!
NEW: Now includes a digital diagram to make it even easier!

Download includes:

  • Arduino Source code
  • Digital diagram image
  • PDF file with detailed instructions

REQUIREMENTS

  • 1 x Arduino Board
  • 1 x 10k Resistor
  • 1 x Pump with reservoir 12V
  • 1 x IRFZ44N Transistor
  • Hot glue
  • 1 x 9v Battery or power supply
  • Some jumper wires to use with breadboard

Useful links to the required items
